Socket: LGA1851
[Chipset] INTEL B860
Form Factor: ATX
Memory Specifications 1: 4 x DDR5 DIMM Slots.
Memory Specifications 2: Dual Channel DDR5 Memory Technology - 4 x DDR5 DIMM Slots - Supports DDR5 non-ECC, un-buffered memory up to 8666+(OC) * 1DPC 1R Up to 8666+ MHz (OC), 5600 MHz Natively. 1DPC 2R Up to 6800+ MHz (OC), 5600. MHz Natively. 2DPC 1R Up to 6533+ MHz (OC), 4800 MHz Natively. 2DPC 2R Up to 5600+ MHz (OC), 4400 MHz Natively. - Supports Clocked Unbuffered DIMM (CUDIMM) - Max. capacity of system memory: 256GB - Supports Intel Extreme Memory Profile (XMP) 3.0x
Phase: 8+1+1+1+1+1+1 Power Phase, Dr. MOS for VCore+GT+SA
【GPU Function】Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. - Intel X LPG Graphics Architecture - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz.
Graphics Output: 1 HDMI
PCIE: 1 PCIe 5.0 x16, 1 PCIe 4.0 x16.
【OC】-
【SLI】-
[Cross Fire] -
Sound Function: Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio
【USB2.0】6 USB 2.0 (2 Rear, 4 Front)
[USB3.2 Gen1] 8 USB 3.2 Gen1 (6 Rear, 2 Front)
USB 3.2 Gen 1 Type-C 2 USB 3.2 Gen1 Type-C (1 Rear,1 Front 1).
【Thunderbolt 4 (USB 4.0)】-
【Thunderbolt 4 Header】-
[SATA3] 4
M.2 Slots: 2 Hyper M.2 (PCIe Gen4x4)
[M.2 Slot Heatsink] 1 Blazing M.2 (PCIe Gen5x4)
【M.2 Wi-Fi】-
Wireless LAN: 802.11be WiFi 7 + Bluetooth
LAN: Realtek 2.5G LAN
【LED】-
